Specifications
Center Electrode Core Material: Copper
Center Electrode Design: Fine Wire
Center Electrode Insulator Tip Projection: 0.12 in
Center Electrode Projection: Mid Projection
Center Electrode Tip Material: Iridium
Electrical Terminal Type: Non-Removable Nut
Grade Type: Performance
Ground Configuration: J-Gap
Ground Electrode Core Material: Nickel
Ground Electrode Quantity: 1
Ground Electrode Tip Design: Taper Cut
Ground Electrode Tip Material: Nickel
Hex Size: 14 mm
Insulator Height: 1.93 in
Insulator Material: Ceramic
Manufacturer Heat Range: 7
Pre-Gap Size: .044 in
Reach: 1.043 in
Resistance: 5000.0 ohm
Resistor Type: Yes
Seat Type: Flat
Skirt: No
Skirt Length: 0.0 in
Thread Diameter: 0.472 in
Thread Size: M12 – 1.25
Washer Type: Crush
Washer(s) Included: Yes
